Introduction
XBZS series vibrating screen is a new type of screening equipment, which classify small and medium and large granular materials.
The screen box is driven by two identical vibration motors or ordinary motors with vibrators, and it rotates in the opposite direction to make the whole screen machine supported on the shock absorber vibrate in a straight line. After the material falls into the screen from the feeding end, it rapidly moves forward, loosens, passes through the screen and completes the screening operation.
The vibration damping system is composed of rubber spring, clamp and supporting seat. The bottom frame is composed of stock bin and chassis. This series of vibro screen can be divided into upper vibration type and lower vibration type. Shock absorber installation can be divided into seat type or hanging type. The vibrating screen design and manufacture is in accordance with customer needs.
Key Features & Advantages
✓ Large inclination angle, small volume and large screening capacity
✓ Specially used for secondary screening under blast furnace trough
✓ Low energy consumption, low price and few spare parts
✓ Light weight, easy to install and process layout
✓ Simple structure and beautiful shape
✓ Screening efficiency is 20% higher than general screens with self-cleaning function
Frequently Asked Questions
Q1: What materials are suitable for the XBZS vibrating screen?
A: It is ideal for classifying small, medium, and large granular materials across various industries including mining, coal, and metallurgy.
Q2: How does the self-cleaning function work?
A: The linear vibration motion and specific inclination angle help prevent material clogging, ensuring a higher screening efficiency compared to general screens.
Q3: Can the installation method be customized?
A: Yes, shock absorber installation can be configured as either seat type or hanging type based on your specific process layout.
Q4: What is the main advantage of the XBZS series in steel plants?
A: This sieve is specially optimized for secondary screening under blast furnace troughs, offering high capacity in a compact volume.
Q5: Is the equipment energy efficient?
A: Yes, it is designed for low energy consumption and requires fewer spare parts, which significantly reduces long-term operating costs.
Q6: What components make up the vibration damping system?
A: The system consists of high-quality rubber springs, clamps, and supporting seats to ensure stable linear vibration and reduced noise.
